Wieland 6-Pole Heavy-Duty Aluminum Industrial Connector Housing
Wieland 6-Pole Heavy-Duty Aluminum Industrial Connector Housing
SKU:IND-7f91bc
Durable Wieland 6-Pole Aluminum Connector Housing with Single Locking Lever. UV Resistant, REACH-SVHC Compliant.
Regular price
$89.99
Regular price
Sale price
$89.99
Unit price
per
Initiate Order
Wieland 6-Pole Heavy-Duty Aluminum Industrial Connector Housing
$89.99
Quantity: 1
Claim Your Seller Account
Wieland 6-Pole Heavy-Duty Aluminum Industrial Connector Housing
$89.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland HOOD BAS GOT GI 6HM32 69 A1 Multi-Pole Heavy-Duty Industrial Connector Housing is a high-quality solution for industrial multipole connector applications. Constructed from durable aluminum with a gray powder coating, this housing features a single locking lever with a threaded hole M32 on the top for secure cable entry. With a high profile design and UV-resistant properties, it ensures reliable performance in a wide temperature range (-40°C to 120°C). Compliant with REACH-SVHC standards, this 6-pole housing is ideal for demanding industrial environments.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
Other
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
HOOD BAS GOT GI 6HM32 69 A1
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
Above
Model Construction
6
Model Emc Version
No
Model Height
70 mm
Model Hinged Lid
No
Model Length
74 mm
Model Locking Mechanism
Single Locking Lever
Model Thread Size M
32
Model Type
Male
Model Type Of Cable
Thread
Model Width
43 mm
Model With Cable Screw Gland
No
Product Compliance Reach Svhc Conformity Status
Compliant
Specifications Number Of Poles
6
Specifications Profile
High
