Wieland 7-Pole Black Female Connector - Outdoor Rated

Name: Wieland 7-Pole Black Female Connector - Outdoor Rated
Brand: Wieland Electric Inc.
SKU: CIR-0c12af
Price: 29.99 USD
Availability: OutOfStock

SKU:CIR-0c12af

Durable Wieland 7-Pole Black Female Connector for outdoor use, IP69 & Type 4X/6P protection, suitable for 6-10mm cables

$29.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Wieland 7-Pole Black Female Connector is a durable and reliable pluggable electrical connector suitable for outdoor applications. With a straight angle of plug and screw connection, it offers secure connections for cables ranging from 6mm to 10mm in diameter. This connector supports a minimum rated voltage of 250V to 400V and a maximum rated voltage of 600V, meeting international standards for electrical connectivity. Its IP69 and Type 4X/6P protection ratings ensure optimal performance in harsh environmental conditions.

Product Specifications

Note Note

Optional water seals on individual contacts for added protection when unmated. Contact us for details.Technical details are subject to change

Specifications Angle Of Plug

Straight

Specifications Color Of Codingcontact Carrier

Black

Specifications Connection Type

Screw Connection

Specifications Number Of Poles

Specifications Type

Female

Technical Data Current According To Canadian Ul Recognized Unite

3 x 16 A + 4 x 2 A (Canada) (Contact us for Additional Combinations) | 3 x 20 A + 4 x 5 A (USA) (Contact us for Additional Combinations)

Technical Data Current According To International Electrotechnic

3 x 20 A + 4 x 5 A

Technical Data Degree Of Protection According To Canadian Ul Lis

Type 4X/6P

Technical Data Degree Of Protection According To International E

IP69

Technical Data Maximum Cable Diameter

10 mm

Technical Data Maximum Rated Voltage

600 V

Technical Data Minimum Cable Diameter

6 mm

Technical Data Minimum Rated Voltage

250 V | 400 V

Technical Data Wire Size According To Canadian Ul Listed United

20 to 14 AWG

Technical Data Wire Size According To International Electrotechn

0.2 to 1.5 mmÂ²
