Wieland 7-Pole Light Blue Male Connector - Outdoor Rated

Name: Wieland 7-Pole Light Blue Male Connector - Outdoor Rated
Brand: Wieland Electric Inc.
SKU: CIR-e119d7
Price: 29.99 USD
Availability: OutOfStock

SKU:CIR-e119d7

Durable Wieland 7-Pole Light Blue Male Connector for outdoor use. IP69 rated, IEC and cULus compliant.

$29.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Wieland 7-Pole Light Blue Male Connector is a durable and reliable electrical connector suitable for outdoor use. With a straight angle plug and screw connection, this connector ensures secure and stable electrical connections. It features a IP69 rating for protection against dust and water ingress, making it ideal for outdoor applications. The connector can accommodate cable diameters ranging from 10mm to 14mm and is rated for voltages up to 600V. Compliant with IEC and cULus standards, this connector is designed to meet the stringent requirements of institutional and government procurement.

Product Specifications

Note Note

Optional water seals on individual contacts for added protection when unmated. Contact us for details.Technical details are subject to change

Specifications Angle Of Plug

Straight

Specifications Color Of Codingcontact Carrier

Light Blue

Specifications Connection Type

Screw Connection

Specifications Number Of Poles

Specifications Type

Male

Technical Data Current According To Canadian Ul Recognized Unite

3 x 16 A + 4 x 2 A (Canada) (Contact us for Additional Combinations) | 3 x 20 A + 4 x 5 A (USA) (Contact us for Additional Combinations)

Technical Data Current According To International Electrotechnic

3 x 20 A + 4 x 5 A

Technical Data Degree Of Protection According To Canadian Ul Lis

Type 4X/6P

Technical Data Degree Of Protection According To International E

IP69

Technical Data Maximum Cable Diameter

14 mm

Technical Data Maximum Rated Voltage

600 V

Technical Data Minimum Cable Diameter

10 mm

Technical Data Minimum Rated Voltage

250 V | 400 V

Technical Data Wire Size According To Canadian Ul Listed United

20 to 14 AWG

Technical Data Wire Size According To International Electrotechn

0.2 to 1.5 mmÂ²
