Wieland 7-Pole Light Gray Female Connector
Wieland 7-Pole Light Gray Female Connector
SKU:CIR-ff88dc
Durable 7-Pole Light Gray Female Connector for secure outdoor electrical connections. IP69 and Type 4X/6P protection standards met.
Regular price
$34.99
Regular price
Sale price
$34.99
Unit price
per
Initiate Order
Wieland 7-Pole Light Gray Female Connector
$34.99
Quantity: 1
Claim Your Seller Account
Wieland 7-Pole Light Gray Female Connector
$34.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 7-Pole Light Gray Female Connector is a durable pluggable electrical connector suitable for outdoor use. With a straight angle of plug and screw connection type, this connector offers a secure and reliable connection. It is designed to accommodate cables ranging from 10mm to 14mm in diameter, with a rated voltage range from 250V to 600V. Meeting IP69 and Type 4X/6P protection standards, this connector ensures safe and efficient electrical connectivity in various environments. Optional water seals for individual contacts provide added protection. Contact us for further details on additional rating combinations.
Product Specifications
Note Note
Optional water seals on individual contacts for added protection when unmated. Contact us for details.Technical details are subject to change
Specifications Angle Of Plug
Straight
Specifications Color Of Codingcontact Carrier
Light Gray
Specifications Connection Type
Screw Connection
Specifications Number Of Poles
7
Specifications Type
Female
Technical Data Current According To Canadian Ul Recognized Unite
3 x 16 A + 4 x 2 A (Canada) (Contact us for Additional Combinations) | 3 x 20 A + 4 x 5 A (USA) (Contact us for Additional Combinations)
Technical Data Current According To International Electrotechnic
3 x 20 A + 4 x 5 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X/6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Cable Diameter
14 mm
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Cable Diameter
10 mm
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Wire Size According To Canadian Ul Listed United
20 to 14 AWG
Technical Data Wire Size According To International Electrotechn
0.2 to 1.5 mm²
