Wieland 7-Pole Light Gray Male Connector
Wieland 7-Pole Light Gray Male Connector
SKU:CIR-e9c1eb
High-performance 7-Pole Light Gray Male Connector for secure outdoor electrical connections. IP69 & 4X/6P rated, supports up to 600V & 3 x 20A + 4 x 5A.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Wieland 7-Pole Light Gray Male Connector
$29.99
Quantity: 1
Claim Your Seller Account
Wieland 7-Pole Light Gray Male Connector
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 7-Pole Light Gray Male Connector is designed for high-performance electrical connections. With screw connection for secure installations, this male connector features a straight plug angle for easy use. It has a robust construction meeting IP69 and Type 4X/6P protection standards, ensuring durability in outdoor environments. Rated for voltages up to 600V and currents as high as 3 x 20A + 4 x 5A, this connector offers reliable power transmission. Optional water seals provide added protection when unmated. Suitable for cables ranging from 6mm to 10mm in diameter, this connector is ideal for outdoor applications in various industries.
Product Specifications
Note Note
Optional water seals on individual contacts for added protection when unmated. Contact us for details.Technical details are subject to change
Specifications Angle Of Plug
Straight
Specifications Color Of Codingcontact Carrier
Light Gray
Specifications Connection Type
Screw Connection
Specifications Number Of Poles
7
Specifications Type
Male
Technical Data Current According To Canadian Ul Recognized Unite
3 x 16 A + 4 x 2 A (Canada) (Contact us for Additional Combinations) | 3 x 20 A + 4 x 5 A (USA) (Contact us for Additional Combinations)
Technical Data Current According To International Electrotechnic
3 x 20 A + 4 x 5 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X/6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Cable Diameter
10 mm
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Cable Diameter
6 mm
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Wire Size According To Canadian Ul Listed United
20 to 14 AWG
Technical Data Wire Size According To International Electrotechn
0.2 to 1.5 mm²
