Wieland 7-Pole Light Gray Male Connector
Wieland 7-Pole Light Gray Male Connector
SKU:CIR-55630a
High-quality Wieland 7-Pole Light Gray Male Connector for outdoor use, IP69 rated, maximum 600V, 3x20A + 4x5A.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Wieland 7-Pole Light Gray Male Connector
$29.99
Quantity: 1
Claim Your Seller Account
Wieland 7-Pole Light Gray Male Connector
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 7-Pole Light Gray Male Connector is a high-quality pluggable electrical connector designed for outdoor use. With an angled 90º plug and screw connection type, this connector ensures secure and reliable connections. It features a IP69 rating for protection against dust and water ingress, making it ideal for outdoor applications. The connector supports a maximum voltage of 600 V and a current of 3 x 20 A + 4 x 5 A, meeting international standards for electrical connectors.
Product Specifications
Note Note
Optional water seals on individual contacts for added protection when unmated. Contact us for details.Technical details are subject to change
Specifications Angle Of Plug
Angled 90º
Specifications Color Of Codingcontact Carrier
Light Gray
Specifications Connection Type
Screw Connection
Specifications Number Of Poles
7
Specifications Type
Male
Technical Data Current According To Canadian Ul Recognized Unite
3 x 16 A + 4 x 2 A (Canada) (Contact us for Additional Combinations) | 3 x 20 A + 4 x 5 A (USA) (Contact us for Additional Combinations)
Technical Data Current According To International Electrotechnic
3 x 20 A + 4 x 5 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X/6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Cable Diameter
14 mm
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Cable Diameter
10 mm
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Wire Size According To Canadian Ul Listed United
20 to 14 AWG
Technical Data Wire Size According To International Electrotechn
0.2 to 1.5 mm²
