Wieland 7-Pole Male Connector, Light Gray, 20A
Wieland 7-Pole Male Connector, Light Gray, 20A
SKU:CIR-034567
High-quality Wieland 7-Pole Male Connector for outdoor use, 20A capacity, IP69 protection, suitable for 10-14mm cables
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Wieland 7-Pole Male Connector, Light Gray, 20A
$24.99
Quantity: 1
Claim Your Seller Account
Wieland 7-Pole Male Connector, Light Gray, 20A
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 7-Pole Male Connector in Light Gray is an essential component of pluggable electrical connections, ideal for outdoor applications. With a straight plug angle and screw connection, this connector features 7 poles capable of handling current up to 20A. It offers a robust IP69 protection rating and accommodates cable diameters ranging from 10mm to 14mm, meeting international standards for reliability and safety.
Product Specifications
Note Note
Optional water seals on individual contacts for added protection when unmated. Contact us for details.Technical details are subject to change
Specifications Angle Of Plug
Straight
Specifications Color Of Codingcontact Carrier
Light Gray
Specifications Connection Type
Screw Connection
Specifications Number Of Poles
7
Specifications Type
Male
Technical Data Current According To Canadian Ul Recognized Unite
3 x 16 A + 4 x 2 A (Canada) (Contact us for Additional Combinations) | 3 x 20 A + 4 x 5 A (USA) (Contact us for Additional Combinations)
Technical Data Current According To International Electrotechnic
3 x 20 A + 4 x 5 A
Technical Data Degree Of Protection According To Canadian Ul Lis
Type 4X/6P
Technical Data Degree Of Protection According To International E
IP69
Technical Data Maximum Cable Diameter
14 mm
Technical Data Maximum Rated Voltage
600 V
Technical Data Minimum Cable Diameter
10 mm
Technical Data Minimum Rated Voltage
250 V | 400 V
Technical Data Wire Size According To Canadian Ul Listed United
20 to 14 AWG
Technical Data Wire Size According To International Electrotechn
0.2 to 1.5 mm²
