Wieland 8113 B/16 OB BLACK Printed Circuit Board (PCB) Connector - 16-Pole, 5mm Pitch
Wieland 8113 B/16 OB BLACK Printed Circuit Board (PCB) Connector - 16-Pole, 5mm Pitch
SKU:PRI-a093ff
High-quality Wieland PCB Connector: 16-Pole, 5mm Pitch, Screw Connection, Grey Color.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Wieland 8113 B/16 OB BLACK Printed Circuit Board (PCB) Connector - 16-Pole, 5mm Pitch
$24.99
Quantity: 1
Claim Your Seller Account
Wieland 8113 B/16 OB BLACK Printed Circuit Board (PCB) Connector - 16-Pole, 5mm Pitch
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 8113 B/16 OB BLACK Printed Circuit Board (PCB) Connector is a high-quality female connector designed for professional applications. With a 5mm pitch and 16 poles, this connector offers reliable wire lead connections in line with the connecting direction. Featuring a screw connection mechanism for secure fittings, this connector is color-coded in grey, with robust construction for durability. With a 2.5 mm² nominal cross-section and a rated current of 12 A, this connector meets stringent industry standards for safety and performance.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Classification Eclass 81 Classification
27440402
Classification Etim 40 Classification
EC002637
Classification Etim 50 Classification
EC002637
Classification Etim 60 Classification
EC002637
Classification Etim 70 Classification
EC002637
Connection Data Maximum Fine Stranded Cross Section
2.5 mm²
Connection Data Maximum Solid Cross Section
2.5 mm²
Connection Data Minimum Fine Stranded Cross Section
0.14 mm²
Connection Data Minimum Solid Cross Section
0.14 mm²
Connection Data Wire Strip Length
6 mm
General Brands
Wieland
General Connection Type
Screw Connection
General Fastening
None
General Marking
No
General Mating Direction Towards Connector
180 º
General Model
8113 B/16 OB BLACK
General Modular Spacing
5 mm
General Number Of Poles
16
General Packaging
Carton
General Soldering Process
None
Other Color
Gray
Other Contact Base Material
Copper Silicone (CuSn)
Other Contact Surface Material
Silicone (Sn)
Other Depth
18.2 mm
Other Height
15 mm
Other Length
80 mm
Other Material Attachment Screw
Copper Silicone (CuSn) | Steel
Other Type Of Insulation Material
Thermoplastic
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant with Exceptions
Product Compliance Rohs Exceptions
III-6(c)
Technical Data Nominal Cross Section
2.5 mm²
Technical Data Overvoltage Category I
1000 V
Technical Data Overvoltage Category Ii
400 V
Technical Data Overvoltage Category Iii
250 V
Technical Data Rated Impulse Voltage
4 kV
Technical Data Ulcsa Voltage Canadian Standards Association Csa
300 V
Technical Data Ulcsa Voltage Underwriters Laboratories Ul
300 V
