Wieland 8113 B/4 OB BLACK PCB Connector
Wieland 8113 B/4 OB BLACK PCB Connector
SKU:PRI-4c53d8
Reliable 4-pole PCB female connector with 5mm pitch, screw connection; rated current 12A; RoHS & REACH-SVHC compliant.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Wieland 8113 B/4 OB BLACK PCB Connector
$24.99
Quantity: 1
Claim Your Seller Account
Wieland 8113 B/4 OB BLACK PCB Connector
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 8113 B/4 OB BLACK PCB Connector is a high-quality 4-pole female connector designed for printed circuit boards (PCB). With a modular spacing of 5mm and screw connection type, this connector ensures secure and reliable electrical connections. It features a robust design with a rated current of 12A and a rated impulse voltage of 4kV, making it ideal for industrial applications. Additionally, its compliance with RoHS and REACH-SVHC standards ensures environmental responsibility.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Classification Eclass 81 Classification
27440402
Classification Etim 40 Classification
EC002637
Classification Etim 50 Classification
EC002637
Classification Etim 60 Classification
EC002637
Classification Etim 70 Classification
EC002637
Connection Data Maximum Fine Stranded Cross Section
2.5 mm²
Connection Data Maximum Solid Cross Section
2.5 mm²
Connection Data Minimum Fine Stranded Cross Section
0.14 mm²
Connection Data Minimum Solid Cross Section
0.14 mm²
Connection Data Wire Strip Length
6 mm
General Brands
Wieland
General Connection Type
Screw Connection
General Fastening
None
General Marking
No
General Mating Direction Towards Connector
180 º
General Model
8113 B/4 OB BLACK
General Modular Spacing
5 mm
General Number Of Poles
4
General Packaging
Carton
General Soldering Process
None
Other Color
Gray
Other Contact Base Material
Copper Silicone (CuSn)
Other Contact Surface Material
Silicone (Sn)
Other Depth
18.2 mm
Other Height
15 mm
Other Length
20 mm
Other Material Attachment Screw
Copper Silicone (CuSn) | Steel
Other Type Of Insulation Material
Thermoplastic
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant with Exceptions
Product Compliance Rohs Exceptions
III-6(c)
Technical Data Nominal Cross Section
2.5 mm²
Technical Data Overvoltage Category I
1000 V
Technical Data Overvoltage Category Ii
400 V
Technical Data Overvoltage Category Iii
250 V
Technical Data Rated Impulse Voltage
4 kV
Technical Data Ulcsa Voltage Canadian Standards Association Csa
300 V
Technical Data Ulcsa Voltage Underwriters Laboratories Ul
300 V
