Wieland 8113 B/8 OB BLACK PCB Connector
Wieland 8113 B/8 OB BLACK PCB Connector
SKU:PRI-3facba
Reliable Wieland 8113 B/8 OB BLACK PCB Connector for secure 8-pole connections on printed circuit boards.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Wieland 8113 B/8 OB BLACK PCB Connector
$24.99
Quantity: 1
Claim Your Seller Account
Wieland 8113 B/8 OB BLACK PCB Connector
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 8113 B/8 OB BLACK Printed Circuit Board (PCB) Connector is a high-quality 8-pole female connector designed for PCB applications. With a modular spacing of 5 mm and a screw connection type, this connector ensures secure and reliable connections. It is color-coded in grey, with no marking for easy identification. This connector is compliant with RoHS standards and features a rated current of 12 A, making it suitable for a wide range of industrial and institutional applications.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Classification Eclass 81 Classification
27440402
Classification Etim 40 Classification
EC002637
Classification Etim 50 Classification
EC002637
Classification Etim 60 Classification
EC002637
Classification Etim 70 Classification
EC002637
Connection Data Maximum Fine Stranded Cross Section
2.5 mm²
Connection Data Maximum Solid Cross Section
2.5 mm²
Connection Data Minimum Fine Stranded Cross Section
0.14 mm²
Connection Data Minimum Solid Cross Section
0.14 mm²
Connection Data Wire Strip Length
6 mm
General Brands
Wieland
General Connection Type
Screw Connection
General Fastening
None
General Marking
No
General Mating Direction Towards Connector
180 º
General Model
8113 B/8 OB BLACK
General Modular Spacing
5 mm
General Number Of Poles
8
General Packaging
Carton
General Soldering Process
None
Other Color
Gray
Other Contact Base Material
Copper Silicone (CuSn)
Other Contact Surface Material
Silicone (Sn)
Other Depth
18.2 mm
Other Height
15 mm
Other Length
40 mm
Other Material Attachment Screw
Copper Silicone (CuSn) | Steel
Other Type Of Insulation Material
Thermoplastic
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant with Exceptions
Product Compliance Rohs Exceptions
III-6(c)
Technical Data Nominal Cross Section
2.5 mm²
Technical Data Overvoltage Category I
1000 V
Technical Data Overvoltage Category Ii
400 V
Technical Data Overvoltage Category Iii
250 V
Technical Data Rated Impulse Voltage
4 kV
Technical Data Ulcsa Voltage Canadian Standards Association Csa
300 V
Technical Data Ulcsa Voltage Underwriters Laboratories Ul
300 V
