Wieland 8113 S/6 G OB PCB Pin Header, 6-Pole - Straight Pin, Marking-Free
Wieland 8113 S/6 G OB PCB Pin Header, 6-Pole - Straight Pin, Marking-Free
SKU:PRI-c43665
Enhance PCB connections with Wieland 8113 S/6 G OB Pin Header. 5mm spacing, 12A current, RoHS & REACH-SVHC compliant.
Regular price
$14.99
Regular price
Sale price
$14.99
Unit price
per
Initiate Order
Wieland 8113 S/6 G OB PCB Pin Header, 6-Pole - Straight Pin, Marking-Free
$14.99
Quantity: 1
Claim Your Seller Account
Wieland 8113 S/6 G OB PCB Pin Header, 6-Pole - Straight Pin, Marking-Free
$14.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your PCB connections with the Wieland 8113 S/6 G OB Printed Circuit Board (PCB) Pin Header. This pin header features a 5mm modular spacing, suitable for wave soldering, and 12A rated current capacity. With impressive overvoltage ratings and compliant with RoHS and REACH-SVHC standards, this header ensures reliable and environmentally friendly performance. The thermoplastic insulation, copper-zinc contact base, and silicone surface material guarantee durability and efficient electrical connectivity. Ideal for various applications requiring a high-quality, compliant PCB pin header.
Product Specifications
Classification Eclass 81 Classification
27440402
Classification Etim 40 Classification
EC002637
Classification Etim 50 Classification
EC002637
Classification Etim 60 Classification
EC002637
Classification Etim 70 Classification
EC002637
General Brands
Wieland
General Fastening
None
General Marking
No
General Mating Direction Towards Circuit Board
90 º
General Model
8113 S/6 G OB
General Modular Spacing
5 mm
General Number Of Levels
1
General Number Of Poles
6
General Packaging
Carton
General Soldering Process
Wave Soldering
Other Color
Gray
Other Contact Base Material
Copper Zinc (CuZn)
Other Contact Surface Material
Silicone (Sn)
Other Depth
8.4 mm
Other Height
12 mm
Other Length
31.4 mm
Other Type Of Insulation Material
Thermoplastic
Product Compliance Reach Svhc Conformity Status
Compliant
Product Compliance Rohs Conformity Status
Compliant
Technical Data Overvoltage Category I
1000 V
Technical Data Overvoltage Category Ii
400 V
Technical Data Overvoltage Category Iii
250 V
Technical Data Rated Current
12 A
Technical Data Rated Impulse Voltage
4 kV
Technical Data Ulcsa Current Canadian Standards Association Csa
15 A
Technical Data Ulcsa Factory Wiring Current
15 A
Technical Data Ulcsa Field Wiring Current
15 A
Technical Data Ulcsa Voltage Canadian Standards Association Csa
300 V
Technical Data Ulcsa Voltage Underwriters Laboratories Ul
300 V
