The Wieland 8142/6 OB Pluggable Printed Circuit Board (PCB) Terminal Block is a reliable 6-pole terminal block with a screw connection designed for PCB applications with stripped headers. With a pitch of 5mm, this terminal block in the series 8142/6 O does not require marking. It features a modular spacing of 5mm, a nominal cross-section of 2.5 mm², and a rated current of 8A. The terminal block meets various international standards including UL/CSA compliance, ensuring safe and efficient electrical connections. Additionally, its RoHS conformity and REACH-SVHC status make it an environmentally compliant choice for both consumer and institutional buyers.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Classification Eclass 81 Classification
27440402
Classification Etim 50 Classification
EC002637
Classification Etim 60 Classification
EC002637
Classification Etim 70 Classification
EC002637
Connection Data Maximum Fine Stranded Cross Section
2.5 mm²
Connection Data Maximum Solid Cross Section
4 mm²
Connection Data Minimum Fine Stranded Cross Section
0.14 mm²
Connection Data Minimum Solid Cross Section
0.14 mm²
Connection Data Wire Strip Length
5 mm
General Brands
Wieland
General Connection Type
Screw Connection
General Marking
No
General Mating Direction Towards Connector
90 º
General Model
8142/6 OB
General Modular Spacing
5 mm
General Number Of Poles
6
General Packaging
Carton
General Soldering Process
None
Other Color
Gray
Other Contact Base Material
Copper Silicon (CuSn)
Other Contact Surface Material
Silicone (Sn)
Other Depth
11.5 mm
Other Height
13 mm
Other Length
30 mm
Other Material Attachment Screw
Steel
Other Type Of Insulation Material
Thermoplastic
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant with Exceptions
Product Compliance Rohs Exceptions
III-6(c)
Technical Data Nominal Cross Section
2.5 mm²
Technical Data Overvoltage Category I
1000 V
Technical Data Overvoltage Category Ii
250 V
Technical Data Overvoltage Category Iii
200 V
Technical Data Rated Current
8 A
Technical Data Rated Impulse Voltage
4 kV
Technical Data Ulcsa Cross Section Canadian Standards Associatio
22-12 AWG
Technical Data Ulcsa Voltage Canadian Standards Association Csa
300 V
Technical Data Ulcsa Voltage Underwriters Laboratories Ul
300 V
