Wieland 8142/8 OB Pluggable PCB Terminal Block
Wieland 8142/8 OB Pluggable PCB Terminal Block
SKU:PRI-ef0ad0
High-quality Wieland 8142/8 OB Pluggable PCB Terminal Block for efficient electrical connections. Meets RoHS standards.
Regular price
$12.99
Regular price
Sale price
$12.99
Unit price
per
Initiate Order
Wieland 8142/8 OB Pluggable PCB Terminal Block
$12.99
Quantity: 1
Claim Your Seller Account
Wieland 8142/8 OB Pluggable PCB Terminal Block
$12.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 8142/8 OB Pluggable Printed Circuit Board (PCB) Terminal Block offers a reliable and efficient solution for your electrical connections. With a modular spacing of 5mm and a screw connection design, this terminal block features an 8-pole configuration without marking. It meets various technical requirements such as a 2.5 mm² nominal cross-section, 8A rated current, and 4kV rated impulse voltage. This terminal block is designed with high-quality materials including copper silicon contacts and silicone surface material for durability and performance excellence. Additionally, it complies with RoHS standards for environmental sustainability.
Product Specifications
Classification Eclass 81 Classification
27440402
Classification Etim 50 Classification
EC002637
Classification Etim 60 Classification
EC002637
Classification Etim 70 Classification
EC002637
Connection Data Maximum Fine Stranded Cross Section
2.5 mm²
Connection Data Maximum Solid Cross Section
4 mm²
Connection Data Minimum Fine Stranded Cross Section
0.14 mm²
Connection Data Minimum Solid Cross Section
0.14 mm²
Connection Data Wire Strip Length
5 mm
General Brands
Wieland
General Connection Type
Screw Connection
General Marking
No
General Mating Direction Towards Connector
90 º
General Model
8142/8 OB
General Modular Spacing
5 mm
General Number Of Poles
8
General Packaging
Carton
General Soldering Process
None
Other Color
Gray
Other Contact Base Material
Copper Silicon (CuSn)
Other Contact Surface Material
Silicone (Sn)
Other Depth
11.5 mm
Other Height
13 mm
Other Length
40 mm
Other Material Attachment Screw
Steel
Other Type Of Insulation Material
Thermoplastic
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant with Exceptions
Product Compliance Rohs Exceptions
III-6(c)
Technical Data Nominal Cross Section
2.5 mm²
Technical Data Overvoltage Category I
1000 V
Technical Data Overvoltage Category Ii
250 V
Technical Data Overvoltage Category Iii
200 V
Technical Data Rated Current
8 A
Technical Data Rated Impulse Voltage
4 kV
Technical Data Ulcsa Cross Section Canadian Standards Associatio
22-12 AWG
Technical Data Ulcsa Voltage Canadian Standards Association Csa
300 V
Technical Data Ulcsa Voltage Underwriters Laboratories Ul
300 V
