Wieland 8142/8 PCB Pin Header, 8 Poles, 5mm Modular Spacing
Wieland 8142/8 PCB Pin Header, 8 Poles, 5mm Modular Spacing
SKU:PRI-f75b14
Wieland 8142/8 PCB Pin Header - 8 Poles, 5mm Spacing, Wave Soldering, 8A, 4kV Protection, RoHS & REACH-SVHC Compliant
Regular price
$25.99
Regular price
Sale price
$25.99
Unit price
per
Initiate Order
Wieland 8142/8 PCB Pin Header, 8 Poles, 5mm Modular Spacing
$25.99
Quantity: 1
Claim Your Seller Account
Wieland 8142/8 PCB Pin Header, 8 Poles, 5mm Modular Spacing
$25.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 8142/8 Printed Circuit Board (PCB) Pin Header is a reliable solution designed for the pluggable terminal block series 8142. With a modular spacing of 5mm and a soldering process suitable for wave soldering, this pin header offers easy installation and secure connections. Rated for 8A current and featuring overvoltage protection up to 4kV, it ensures safe and efficient electrical connections. The thermoplastic insulation material and copper zinc contact base provide durability and reliability. Compliant with RoHS and REACH-SVHC standards, this pin header meets essential environmental regulations.
Product Specifications
Classification Eclass 81 Classification
27440402
Classification Etim 40 Classification
EC002637
Classification Etim 50 Classification
EC002637
Classification Etim 60 Classification
EC002637
Classification Etim 70 Classification
EC002637
General Brands
Wieland
General Fastening
None
General Marking
No
General Mating Direction Towards Circuit Board
90 º
General Model
PCB PIN HEADER 8142/8
General Modular Spacing
5 mm
General Number Of Levels
1
General Number Of Poles
8
General Packaging
Carton
General Soldering Process
Wave Soldering
Other Color
Black
Other Contact Base Material
Copper Zinc (CuZn)
Other Contact Surface Material
Silicone (Sn)
Other Depth
2.8 mm
Other Height
14.5 mm
Other Length
40 mm
Other Type Of Insulation Material
Thermoplastic
Product Compliance Reach Svhc Conformity Status
Compliant
Product Compliance Rohs Conformity Status
Compliant
Technical Data Overvoltage Category I
1000 V
Technical Data Overvoltage Category Ii
250 V
Technical Data Overvoltage Category Iii
200 V
Technical Data Rated Current
8 A
Technical Data Rated Impulse Voltage
4 kV
Technical Data Ulcsa Current Canadian Standards Association Csa
15 A
Technical Data Ulcsa Factory Wiring Current
15 A
Technical Data Ulcsa Field Wiring Current
15 A
Technical Data Ulcsa Voltage Canadian Standards Association Csa
300 V
Technical Data Ulcsa Voltage Underwriters Laboratories Ul
300 V
