Wieland 8142 Z/4 OB PCB Terminal Block
Wieland 8142 Z/4 OB PCB Terminal Block
SKU:PRI-a2e55c
Wieland 8142 Z/4 OB PCB Terminal Block - 4-Pole Screw Connection with 5mm Pitch, Nominal 2.5mm², RoHS Compliant
Regular price
$12.99
Regular price
Sale price
$12.99
Unit price
per
Initiate Order
Wieland 8142 Z/4 OB PCB Terminal Block
$12.99
Quantity: 1
Claim Your Seller Account
Wieland 8142 Z/4 OB PCB Terminal Block
$12.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 8142 Z/4 OB Pluggable Printed Circuit Board (PCB) Terminal Block features a screw connection in rising cage technology, suitable for PCB with stripped headers. This terminal block is a 4-pole connector with a modular spacing of 5mm in the 8142 Z/4 OB series. It offers a nominal cross-section of 2.5 mm², rated current of 3A, and overvoltage protection up to 4kV. With RoHS and REACH-SVHC compliance, this terminal block ensures reliable and safe connections in various applications.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Classification Eclass 81 Classification
27440402
Classification Etim 40 Classification
EC002637
Classification Etim 50 Classification
EC002637
Classification Etim 60 Classification
EC002637
Classification Etim 70 Classification
EC002637
Connection Data Maximum Fine Stranded Cross Section
2.5 mm²
Connection Data Maximum Solid Cross Section
2.5 mm²
Connection Data Minimum Fine Stranded Cross Section
0.5 mm²
Connection Data Minimum Solid Cross Section
0.5 mm²
Connection Data Wire Strip Length
6 mm
General Brands
Wieland
General Connection Type
Screw Connection
General Marking
No
General Mating Direction Towards Connector
90 º
General Model
8142 Z/4 OB
General Modular Spacing
5 mm
General Number Of Levels
1
General Number Of Poles
4
General Packaging
Carton
General Soldering Process
None
Other Color
Gray
Other Contact Base Material
Copper Zinc (CuZn)
Other Contact Surface Material
Silicone (Sn)
Other Depth
12.6 mm
Other Height
10.9 mm
Other Length
20 mm
Other Material Attachment Screw
Steel
Other Type Of Insulation Material
Thermoplastic
Product Compliance Reach Svhc Conformity Status
Compliant
Product Compliance Rohs Conformity Status
Compliant
Technical Data Nominal Cross Section
2.5 mm²
Technical Data Overvoltage Category I
1000 V
Technical Data Overvoltage Category Ii
320 V
Technical Data Overvoltage Category Iii
200 V
Technical Data Rated Current
3 A
Technical Data Rated Impulse Voltage
4 kV
Technical Data Ulcsa Cross Section Canadian Standards Associatio
20-14 AWG
Technical Data Ulcsa Cross Section Underwriters Laboratories Ul
20-14 AWG
Technical Data Ulcsa Voltage Canadian Standards Association Csa
300 V
Technical Data Ulcsa Voltage Underwriters Laboratories Ul
300 V
