Wieland 8142 ZP/2 Pluggable PCB Terminal Block
Wieland 8142 ZP/2 Pluggable PCB Terminal Block
SKU:PRI-27a6d8
Secure and efficient 2-pole Pluggable PCB Terminal Block by Wieland.
Regular price
$8.99
Regular price
Sale price
$8.99
Unit price
per
Initiate Order
Wieland 8142 ZP/2 Pluggable PCB Terminal Block
$8.99
Quantity: 1
Claim Your Seller Account
Wieland 8142 ZP/2 Pluggable PCB Terminal Block
$8.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 8142 ZP/2 OB Pluggable Printed Circuit Board (PCB) Terminal Block is a high-quality 2-pole terminal block designed for PCB connections with stripped headers. Featuring screw connection in rising cage technology and a modular spacing of 5mm, this terminal block ensures secure and reliable connections. With a nominal cross-section of 2.5 mm² and a rated current of 12 A, it meets stringent electrical requirements. This terminal block is compliant with RoHS standards and offers exceptional overvoltage protection, making it ideal for various applications in both consumer and institutional settings.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Classification Eclass 81 Classification
27440402
Classification Etim 40 Classification
EC002637
Classification Etim 50 Classification
EC002637
Classification Etim 60 Classification
EC002637
Classification Etim 70 Classification
EC002637
Connection Data Maximum Fine Stranded Cross Section
2.5 mm²
Connection Data Maximum Solid Cross Section
2.5 mm²
Connection Data Minimum Fine Stranded Cross Section
0.14 mm²
Connection Data Minimum Solid Cross Section
0.14 mm²
Connection Data Wire Strip Length
6 mm
General Brands
Wieland
General Connection Type
Screw Connection
General Mating Direction Towards Connector
90 º
General Model
8142 ZP/2 OB
General Modular Spacing
5 mm
General Number Of Levels
1
General Number Of Poles
2
General Packaging
Carton
General Soldering Process
None
Note Note
Maximum conductor cross section (flex., stranded) with ferrule 2.5 mm²Fine stranded and stranded conductors require cable end sleeve
Other Color
Black
Other Contact Base Material
Copper Zinc (CuZn)
Other Contact Surface Material
Silicone (Sn)
Other Depth
12.95 mm
Other Height
11.6 mm
Other Length
10 mm
Other Material Attachment Screw
Steel
Other Tightening Torque Note
Recommended tightening torque 0.3 - 0.4 Nm
Other Type Of Insulation Material
Thermoplastic
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant with Exceptions
Product Compliance Rohs Exceptions
III-6(c)
Technical Data Nominal Cross Section
2.5 mm²
Technical Data Overvoltage Category I
1000 V
Technical Data Overvoltage Category Ii
600 V
Technical Data Overvoltage Category Iii
250 V
Technical Data Rated Current
12 A
Technical Data Rated Impulse Voltage
4 kV
