Wieland 8191/2 OB PCB Terminal Block
Wieland 8191/2 OB PCB Terminal Block
SKU:PRI-01fde3
Wieland 2-pole PCB Terminal Block for secure and reliable electrical connections. RoHS and REACH compliant.
Regular price
$12.99
Regular price
Sale price
$12.99
Unit price
per
Initiate Order
Wieland 8191/2 OB PCB Terminal Block
$12.99
Quantity: 1
Claim Your Seller Account
Wieland 8191/2 OB PCB Terminal Block
$12.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 8191/2 OB Printed Circuit Board (PCB) Terminal Block is a 2-pole connector featuring a modular spacing of 5mm with screw connections for secure attachment. With a rated current of 16A and a 4kV rated impulse voltage, this terminal block ensures reliable electrical connections. It is designed for easy wave soldering and supports wire strip lengths of up to 6.5mm. Compliant with RoHS and REACH regulations, this terminal block meets industry standards for lead-free and environmentally friendly manufacturing processes.
Product Specifications
Classification Eclass 81 Classification
27440401
Classification Etim 40 Classification
EC002643
Classification Etim 50 Classification
EC002643
Classification Etim 60 Classification
EC002643
Classification Etim 70 Classification
EC002643
Connection Data Maximum Fine Stranded Cross Section
2.5 mm²
Connection Data Maximum Solid Cross Section
4 mm²
Connection Data Minimum Fine Stranded Cross Section
0.14 mm²
Connection Data Minimum Solid Cross Section
0.14 mm²
General Conductor To Circuit Board
180 º
General Connection Type
Screw Connection
General Insulation Plate
No
General Integrated Test Socket
Yes
General Marking
No
General Modular Spacing
5 mm
General Number Of Levels
1
General Number Of Poles
2
General Packaging
Carton
General Retaining Pins
No
General Soldering Process
Wave Soldering
Other Color
Gray
Other Contact Base Material
E-Copper (E-Cu)
Other Contact Surface Material
Silicone (Sn)
Other Depth
16 mm
Other Height
9.5 mm
Other Length
10.85 mm
Other Material Attachment Screw
Steel
Other Tightening Torque Note
If soldered additional mechanical fixing necessary
Other Type Of Insulation Material
Thermoplastic
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant with Exceptions
Technical Data Overvoltage Category I
1000 V
Technical Data Overvoltage Category Ii
690 V
Technical Data Overvoltage Category Iii
250 V
Technical Data Rated Impulse Voltage
4 kV
Technical Data Ulcsa Voltage Canadian Standards Association Csa
300 V
Technical Data Ulcsa Voltage Underwriters Laboratories Ul
300 V
