Wieland 8213 S/3 G OB 3-Pole PCB Pin Header
Wieland 8213 S/3 G OB 3-Pole PCB Pin Header
SKU:PRI-45cf22
High-quality Wieland PCB Pin Header with 3 straight pins, 5.08mm spacing, wave soldering compatible. Meets RoHS & REACH-SVHC standards.
Regular price
$14.99
Regular price
Sale price
$14.99
Unit price
per
Initiate Order
Wieland 8213 S/3 G OB 3-Pole PCB Pin Header
$14.99
Quantity: 1
Claim Your Seller Account
Wieland 8213 S/3 G OB 3-Pole PCB Pin Header
$14.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland 8213 S/3 G OB Printed Circuit Board (PCB) Pin Header is a premium solution designed for reliable connections in electronic applications. This PCB pin header features straight pins with a 5.08mm modular spacing and is ideal for wave soldering processes. With a rated current of 12A and overvoltage categories I-III specifications, this pin header ensures safe and efficient performance. It complies with RoHS and REACH-SVHC standards, providing assurance of environmental sustainability.
Product Specifications
Classification Eclass 81 Classification
27440402
Classification Etim 40 Classification
EC002637
Classification Etim 50 Classification
EC002637
Classification Etim 60 Classification
EC002637
Classification Etim 70 Classification
EC002637
General Brands
Wieland
General Fastening
None
General Marking
No
General Mating Direction Towards Circuit Board
90 º
General Model
8213 S/3 G OB
General Modular Spacing
5.08 mm
General Number Of Levels
1
General Number Of Poles
3
General Packaging
Carton
General Soldering Process
Wave Soldering
Other Color
Gray
Other Contact Base Material
Copper Zinc (CuZn)
Other Contact Surface Material
Silicone (Sn)
Other Depth
8.4 mm
Other Height
12 mm
Other Length
16.64 mm
Other Type Of Insulation Material
Thermoplastic
Product Compliance Reach Svhc Conformity Status
Compliant
Product Compliance Rohs Conformity Status
Compliant
Technical Data Overvoltage Category I
100 V
Technical Data Overvoltage Category Ii
400 V
Technical Data Overvoltage Category Iii
250 V
Technical Data Rated Current
12 A
Technical Data Rated Impulse Voltage
4 kV
Technical Data Ulcsa Current Canadian Standards Association Csa
15 A
Technical Data Ulcsa Factory Wiring Current
15 A
Technical Data Ulcsa Field Wiring Current
15 A
Technical Data Ulcsa Voltage Canadian Standards Association Csa
300 V
Technical Data Ulcsa Voltage Underwriters Laboratories Ul
300 V
