Wieland Aluminum 16-Pole Industrial Connector Housing M32 A1
Wieland Aluminum 16-Pole Industrial Connector Housing M32 A1
SKU:IND-4085c9
Durable Wieland Aluminum 16-Pole Connector Housing with secure locking mechanism & UV resistance.
Regular price
$79.99
Regular price
Sale price
$79.99
Unit price
per
Initiate Order
Wieland Aluminum 16-Pole Industrial Connector Housing M32 A1
$79.99
Quantity: 1
Claim Your Seller Account
Wieland Aluminum 16-Pole Industrial Connector Housing M32 A1
$79.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland Aluminum 16-Pole Industrial Connector Housing M32 A1 is a heavy-duty solution for industrial applications. Constructed with durable aluminum and a powder-coated gray surface, this housing is designed for reliability in harsh environments. Featuring a low-profile design, double locking levers, and threaded cable entry, it ensures secure connections with ease of installation. With a temperature range from -40ºC to 120ºC and UV resistance, it guarantees performance in diverse conditions. This product complies with REACH-SVHC standards, offering peace of mind regarding environmental regulations.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
Other
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
HOOD BAS GOT GC 16 M32 A1
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
Above
Model Construction
16
Model Emc Version
No
Model Height
60 mm
Model Hinged Lid
No
Model Length
94 mm
Model Locking Mechanism
Double Locking Levers
Model Thread Size M
32
Model Type
Male
Model Type Of Cable
Thread
Model Width
56 mm
Model With Cable Screw Gland
No
Product Compliance Reach Svhc Conformity Status
Compliant
Specifications Number Of Poles
16
Specifications Profile
Low
