Wieland Aluminum 24-Pole Industrial Multi-Pole Connector Housing
Wieland Aluminum 24-Pole Industrial Multi-Pole Connector Housing
SKU:IND-161fa9
Durable Wieland aluminum housing with 24 poles, hinged lid, and IP54 protection. Ideal for industrial applications.
Regular price
$89.99
Regular price
Sale price
$89.99
Unit price
per
Initiate Order
Wieland Aluminum 24-Pole Industrial Multi-Pole Connector Housing
$89.99
Quantity: 1
Claim Your Seller Account
Wieland Aluminum 24-Pole Industrial Multi-Pole Connector Housing
$89.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland BOTTOM BAS GUT GP 24 A Multi-Pole Heavy-Duty Industrial Connector Housing is a reliable solution for industrial applications. Constructed from aluminum with a gray powder coating, this housing ensures durability and resistance to harsh environments. Featuring a single locking lever and a hinged lid, it offers easy access and secure connections. With a low profile design and IP54 protection rating, it meets stringent industrial standards. This 24-pole connector housing is temperature-resistant from -40°C to 120°C, making it ideal for versatile operational conditions.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
IP54
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
BOTTOM BAS GUT GP 24 A
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
None
Model Construction
24
Model Emc Version
No
Model Height
28 mm
Model Hinged Lid
Yes
Model Length
140 mm
Model Locking Mechanism
Single Locking Lever
Model Type
Equipment Mounted (Feed-Through)
Model Type Of Cable
None
Model Width
43 mm
Model With Cable Screw Gland
No
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant with Exceptions
Product Compliance Rohs Exceptions
III-6(a)
Specifications Number Of Poles
24
Specifications Profile
Low
