Wieland Aluminum 6-Pole Industrial Connector Housing
Wieland Aluminum 6-Pole Industrial Connector Housing
SKU:IND-66fa59
Durable Wieland Aluminum 6-Pole industrial connector housing with single locking lever and M25 thread hole. UV resistant and REACH-SVHC compliant.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Wieland Aluminum 6-Pole Industrial Connector Housing
$49.99
Quantity: 1
Claim Your Seller Account
Wieland Aluminum 6-Pole Industrial Connector Housing
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland Aluminum 6-Pole Industrial Connector Housing is a heavy-duty solution for industrial applications. Constructed with high-quality aluminum and featuring a single locking lever, this housing ensures secure cable connections. With a threaded hole M25 on top for easy installation, this low-profile housing is designed to withstand extreme temperatures ranging from -40°C to 120°C. Its UV resistance and compliance with REACH-SVHC regulations make it a reliable choice for demanding environments.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC00043
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
HOOD BAS GOT GL 6 M25 A1
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
Above
Model Construction
6
Model Emc Version
No
Model Height
53 mm
Model Hinged Lid
No
Model Length
74 mm
Model Locking Mechanism
Single Locking Lever
Model Thread Size M
25
Model Type
Equipment Mounted (Feed-Through)
Model Type Of Cable
Thread
Model Width
43 mm
Model With Cable Screw Gland
No
Product Compliance Reach Svhc Conformity Status
Compliant
Specifications Number Of Poles
6
Specifications Profile
Low
