Wieland Aluminum Industrial Multipole Connector Housing-HD GG 15 M20
Wieland Aluminum Industrial Multipole Connector Housing-HD GG 15 M20
SKU:IND-9b3a6a
Durable Wieland Aluminum Industrial Connector Housing - IP54, 15-Pole, UV Resistant
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Wieland Aluminum Industrial Multipole Connector Housing-HD GG 15 M20
$49.99
Quantity: 1
Claim Your Seller Account
Wieland Aluminum Industrial Multipole Connector Housing-HD GG 15 M20
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland HOOD HD GOT GG 15 M20 50 A0 Multi-Pole Heavy-Duty Industrial Connector Housing is a robust solution designed for industrial applications. Constructed from durable aluminum with a gray powder coating, this 15-pole connector housing features a single locking lever and a cable gland M20 on the right side, ensuring IP54 protection. With a temperature range from -40°C to 120°C, UV resistance, and compliance with RoHS regulations, this housing meets stringent industry standards for quality and safety.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
IP54
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
HOOD HD GOT GG 15 M20 50 A0
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
Sideways
Model Construction
10/15
Model Emc Version
No
Model Height
64 mm
Model Hinged Lid
No
Model Length
73 mm
Model Locking Mechanism
Single Locking Lever
Model Thread Size M
20
Model Type
Male
Model Type Of Cable
Gland nut
Model Width
33 mm
Model With Cable Screw Gland
Yes
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant with Exceptions
Product Compliance Rohs Exceptions
III-6(c)
Specifications Number Of Poles
15
Specifications Profile
Low
