Wieland Aluminum Multi-Pole Industrial Connector Housing - Threaded M32, 16-Pole
Wieland Aluminum Multi-Pole Industrial Connector Housing - Threaded M32, 16-Pole
SKU:IND-05e4e8
Durable Wieland Aluminum Multi-Pole Industrial Connector Housing with 16-Pole construction and double locking lever for secure connections.
Regular price
$89.99
Regular price
Sale price
$89.99
Unit price
per
Initiate Order
Wieland Aluminum Multi-Pole Industrial Connector Housing - Threaded M32, 16-Pole
$89.99
Quantity: 1
Claim Your Seller Account
Wieland Aluminum Multi-Pole Industrial Connector Housing - Threaded M32, 16-Pole
$89.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland BOTTOM BAS GUT GC 16HM32 50 A1 Multi-Pole Heavy-Duty Industrial Connector Housing is a robust solution designed for industrial applications. Constructed from durable aluminum with a gray powder-coating, this surface-mounting housing features a 16-pole configuration suitable for demanding environments. The double locking lever ensures secure cable connections, while the UV resistance and wide temperature range (-40°C to 120°C) guarantee longevity and reliability. Compliant with REACH-SVHC regulations, this housing meets industry standards for quality and performance.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
Other
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
BOTTOM BAS GUT GC 16HM32 50 A1
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
Sideways
Model Construction
16H
Model Emc Version
No
Model Height
75 mm
Model Hinged Lid
No
Model Length
117 mm
Model Locking Mechanism
Double Locking Levers
Model Thread Size M
32
Model Type
Surface Mounting (Base)
Model Type Of Cable
Thread
Model Width
57 mm
Model With Cable Screw Gland
No
Product Compliance Reach Svhc Conformity Status
Compliant
Specifications Number Of Poles
16
Specifications Profile
Low
