Wieland BAS BUS 10 2,5 69 Industrial Connector Insert
Wieland BAS BUS 10 2,5 69 Industrial Connector Insert
SKU:IND-c0ef73
Get reliable and efficient connectivity with the Wieland BAS BUS 10 2,5 69 Industrial Connector Insert. Designed for industrial use with 10 poles, rated current of 16A, and rated voltage of 690V. RoHS compliant and durable construction.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Wieland BAS BUS 10 2,5 69 Industrial Connector Insert
$24.99
Quantity: 1
Claim Your Seller Account
Wieland BAS BUS 10 2,5 69 Industrial Connector Insert
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland BAS BUS 10 2,5 69 Industrial Connector Insert is a reliable solution designed for industrial applications. Featuring a 10-pole female insert with a rated current of 16A and a rated voltage of 690V, this connector insert ensures secure and efficient connectivity. With tin-plated contacts, it offers enhanced conductivity and durability. The gray color, V0 inflammability class, and a wide operating temperature range from -40°C to 120°C make it ideal for versatile industrial settings. This connector insert is easy to install with screw connections and provides wire protection for added safety. With compliance to RoHS standards and robust construction, it meets the stringent requirements of industrial procurement.
Product Specifications
Classification Eclass 81 Classification
27440205
Classification Etim 40 Classification
EC000438
Classification Etim 50 Classification
EC000438
Classification Etim 60 Classification
EC000438
Classification Etim 70 Classification
EC000438
Connection Data Connection Type
Screw Connection
Connection Data Maximum Conductor Diameter Rigid Solidstranded
2.5 mm²
Connection Data Minimum Conductor Diameter Rigid Solidstranded
0.5 mm²
Connection Data Number Of Poles
8
Connection Data Plus Switching Contacts
2
Connection Data Protective Contact
Yes
Connection Data Total Number Of Poles Without Ground Contact
10
Connection Data With Wire Protection
Yes
Contacts Contact Material
Copper Alloy
Contacts Contact Resistance
⤠1.5 mΩ
Contacts Surface
Tin-Plated
Contacts Wire Strip Length
7 mm
General Brands
Wieland
General Color
Gray
General Inflammability Class Of Insulation Material According Wi
V0
General Mating Cycles
200
General Maximum Operating Temperature
120 ºC
General Minimum Operating Temperature
-40 ºC
General Model
FEMALE INSERT BAS BUS 10 2,5 69
General Modular Version
No
General Pollution Degree
3
General Type
Female Insert
Model With Housing
No
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant/Exempted
Product Compliance Rohs Exceptions
III-6(c)
Screws Head Design Clamping Screws
H1/0.5-0.7 N·m
Screws Head Design Ground Conductor Screws
H2/1.2-1.6 N·m
Screws Head Design Mounting Screws
H1/0.5-0.7 N·m
Technical Data Din En 61984 Maximum Rated Voltage Faceground
690 V
Technical Data Din En 61984 Nominal Voltage
690 V
Technical Data Din En 61984 Rated Impulse Voltage
8 kV
Technical Data Ulcsa Maximum Rated Voltage According To Underwri
600 V
