Wieland BAS STS 16 2,5 69 Industrial Connector Insert - Male 16-Pole 690V
Wieland BAS STS 16 2,5 69 Industrial Connector Insert - Male 16-Pole 690V
SKU:IND-17bf03
Reliable Wieland BAS STS 16 2,5 69 Industrial Connector Insert - Male 16-Pole, 690V, Tin-Plated Contacts, V0 Inflammability, RoHS Compliant
Regular price
$28.99
Regular price
Sale price
$28.99
Unit price
per
Initiate Order
Wieland BAS STS 16 2,5 69 Industrial Connector Insert - Male 16-Pole 690V
$28.99
Quantity: 1
Claim Your Seller Account
Wieland BAS STS 16 2,5 69 Industrial Connector Insert - Male 16-Pole 690V
$28.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland BAS STS 16 2,5 69 Industrial Connector Insert is a reliable solution for industrial connectivity needs. This male insert features 16 poles with a rated current of 16A and a rated voltage of 690V, equipped with tin-plated contacts for enhanced conductivity. With a screw connection type and sturdy copper alloy contact material, it ensures secure and efficient power transmission. Designed with a V0 inflammability class and meeting RoHS conformity standards, this insert prioritizes safety while offering high performance. From its wide operating temperature range of -40°C to 120°C to its compliance with UL and CSA ratings, this connector insert is suitable for a variety of industrial applications.
Product Specifications
Classification Eclass 81 Classification
27440205
Classification Etim 30 Classification
EC000438
Classification Etim 40 Classification
EC000438
Classification Etim 50 Classification
EC000438
Classification Etim 60 Classification
EC000438
Classification Etim 70 Classification
EC000438
Connection Data Connection Type
Screw Connection
Connection Data Maximum Conductor Diameter Rigid Solidstranded
2.5 mm²
Connection Data Minimum Conductor Diameter Rigid Solidstranded
0.5 mm²
Connection Data Number Of Poles
14
Connection Data Plus Switching Contacts
2
Connection Data Protective Contact
Yes
Connection Data Total Number Of Poles Without Ground Contact
16
Connection Data With Wire Protection
Yes
Contacts Contact Material
Copper Alloy
Contacts Contact Resistance
⤠1.5 mΩ
Contacts Surface
Tin-Plated
Contacts Wire Strip Length
7 mm
General Brands
Wieland
General Color
Gray
General Inflammability Class Of Insulation Material According Wi
V0
General Mating Cycles
200
General Maximum Operating Temperature
120 ºC
General Minimum Operating Temperature
-40 ºC
General Model
MALE INSERT BAS STS 16 2,5 69
General Modular Version
No
General Pollution Degree
3
General Type
Male Insert
Model With Housing
No
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant/Exempted
Product Compliance Rohs Exceptions
III-6(c)
Screws Head Design Clamping Screws
H1/0.5-0.7 N·m
Screws Head Design Ground Conductor Screws
H2/1.2-1.6 N·m
Technical Data Din En 61984 Maximum Rated Voltage Faceground
690 V
Technical Data Din En 61984 Nominal Voltage
690 V
Technical Data Din En 61984 Rated Impulse Voltage
8 kV
Technical Data Ulcsa Maximum Rated Voltage According To Underwri
600 V
