Wieland BOTTOM BAS GUT GA 10 A Heavy-Duty Industrial Connector Housing
Wieland BOTTOM BAS GUT GA 10 A Heavy-Duty Industrial Connector Housing
SKU:IND-9cf7d6
Wieland heavy-duty industrial connector housing with aluminum construction, IP54 protection, and 10 poles for secure connections.
Regular price
$89.99
Regular price
Sale price
$89.99
Unit price
per
Initiate Order
Wieland BOTTOM BAS GUT GA 10 A Heavy-Duty Industrial Connector Housing
$89.99
Quantity: 1
Claim Your Seller Account
Wieland BOTTOM BAS GUT GA 10 A Heavy-Duty Industrial Connector Housing
$89.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland BOTTOM BAS GUT GA 10 A Multi-Pole Heavy-Duty Industrial Connector Housing is a reliable solution for industrial applications. Constructed from aluminum with a powder coating, this connector housing offers a degree of protection of IP54, ensuring durability even in challenging environments. With a low-profile design and 10 poles, it features double locking levers for secure connections. Meeting REACH-SVHC standards, this connector housing is versatile and UV resistant, suitable for a temperature range from -40°C to 120°C.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
IP54
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
BOTTOM BAS GUT GA 10 A
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
None
Model Construction
10
Model Emc Version
No
Model Height
28 mm
Model Hinged Lid
No
Model Length
93 mm
Model Locking Mechanism
Double Locking Levers
Model Type
Equipment Mounted (Feed-Through)
Model Type Of Cable
None
Model Width
43 mm
Model With Cable Screw Gland
No
Product Compliance Reach Svhc Conformity Status
Compliant
Specifications Number Of Poles
10
Specifications Profile
Low
