Wieland BOTTOM BAS GUT GA 24 A Industrial Connector Housing
Wieland BOTTOM BAS GUT GA 24 A Industrial Connector Housing
SKU:IND-e5c504
Durable aluminum multi-pole industrial connector housing with double locking lever, IP54 protection, and 24 poles.
Regular price
$69.99
Regular price
Sale price
$69.99
Unit price
per
Initiate Order
Wieland BOTTOM BAS GUT GA 24 A Industrial Connector Housing
$69.99
Quantity: 1
Claim Your Seller Account
Wieland BOTTOM BAS GUT GA 24 A Industrial Connector Housing
$69.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland BOTTOM BAS GUT GA 24 A Multi-Pole Heavy-Duty Industrial Connector Housing is a top-of-the-line solution for industrial applications. Constructed with durable aluminum and featuring a double locking lever, this housing ensures secure connections. With a low profile design and 24 poles, it meets IP54 standards for dust and water resistance. Operating reliably in temperatures ranging from -40 to 120 °C, this connector housing is UV resistant and compliant with REACH-SVHC regulations.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
IP54
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
BOTTOM BAS GUT GA 24 A
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
None
Model Construction
24
Model Emc Version
No
Model Height
28 mm
Model Hinged Lid
No
Model Length
140 mm
Model Locking Mechanism
Double Locking Levers
Model Type
Equipment Mounted (Feed-Through)
Model Type Of Cable
None
Model Width
57 mm
Model With Cable Screw Gland
No
Product Compliance Reach Svhc Conformity Status
Compliant
Specifications Number Of Poles
24
Specifications Profile
Low
