Wieland Bottom BAS GUT GA 32 50 A Multi-Pole Connector Housing
Wieland Bottom BAS GUT GA 32 50 A Multi-Pole Connector Housing
SKU:IND-41de22
High-quality Wieland industrial connector housing with 32 poles, double locking lever, and IP54 protection for industrial applications.
Regular price
$89.99
Regular price
Sale price
$89.99
Unit price
per
Initiate Order
Wieland Bottom BAS GUT GA 32 50 A Multi-Pole Connector Housing
$89.99
Quantity: 1
Claim Your Seller Account
Wieland Bottom BAS GUT GA 32 50 A Multi-Pole Connector Housing
$89.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland Bottom BAS GUT GA 32 50 A Multi-Pole Connector Housing is an industrial-grade solution designed for heavy-duty applications. Constructed from aluminum with a powder-coated gray finish, this low-profile housing features a 32-pole configuration and a secure double locking lever mechanism, ensuring reliable connections. With a temperature range from -40°C to 120°C and an IP54 rating, it offers durability and protection in various environments. Compliant with REACH-SVHC standards, this housing guarantees safety and quality.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
IP54
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
BOTTOM BAS GUT GA 32 50 A
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
None
Model Construction
32
Model Emc Version
No
Model Height
35 mm
Model Hinged Lid
No
Model Length
124 mm
Model Locking Mechanism
Double Locking Levers
Model Type
Equipment Mounted (Feed-Through)
Model Type Of Cable
None
Model Width
84 mm
Model With Cable Screw Gland
No
Product Compliance Reach Svhc Conformity Status
Compliant
Specifications Number Of Poles
32
Specifications Profile
Low
