Wieland Bottom Bas GUT GB 10 M25 A Industrial Connector Housing
Wieland Bottom Bas GUT GB 10 M25 A Industrial Connector Housing
SKU:IND-23aa14
Durable Wieland Industrial Connector Housing with 10 poles, IP54 protection, and aluminum construction. RoHS compliant.
Regular price
$89.99
Regular price
Sale price
$89.99
Unit price
per
Initiate Order
Wieland Bottom Bas GUT GB 10 M25 A Industrial Connector Housing
$89.99
Quantity: 1
Claim Your Seller Account
Wieland Bottom Bas GUT GB 10 M25 A Industrial Connector Housing
$89.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland Bottom Bas GUT GB 10 M25 A Multi-Pole Heavy-Duty Industrial Connector Housing is a durable and reliable solution for industrial multipole connections. Constructed from aluminum with a gray powder coating, this connector housing features a low profile design with a 10-pole configuration. It includes protective covers and cable glands on both sides, offering IP54 protection against dust and moisture. With a temperature range from -40°C to 120°C, double locking levers for secure mounting, and a thread-based cable entry system, this housing provides robust performance in demanding industrial environments. Compliant with RoHS standards and featuring UV resistance, it ensures safety and longevity in various applications.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
Other
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
BOTTOM BAS GUT GB 10 M25 A
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
Two-sided
Model Construction
10
Model Emc Version
No
Model Height
55 mm
Model Hinged Lid
Yes
Model Length
94 mm
Model Locking Mechanism
Double Locking Levers
Model Thread Size M
25
Model Type
Surface Mounting (Base)
Model Type Of Cable
Thread
Model Width
52 mm
Model With Cable Screw Gland
No
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant with Exceptions
Product Compliance Rohs Exceptions
III-6(a)
Specifications Number Of Poles
10
Specifications Profile
Low
