Wieland Bottom Bas GUT GE 16A Industrial Connector Housing
Wieland Bottom Bas GUT GE 16A Industrial Connector Housing
SKU:IND-2ccd89
High-quality Wieland industrial connector housing with aluminum construction, double-locking lever, hinged lid, and IP54 protection.
Regular price
$59.99
Regular price
Sale price
$59.99
Unit price
per
Initiate Order
Wieland Bottom Bas GUT GE 16A Industrial Connector Housing
$59.99
Quantity: 1
Claim Your Seller Account
Wieland Bottom Bas GUT GE 16A Industrial Connector Housing
$59.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland Bottom Bas GUT GE 16A Multi-Pole Heavy-Duty Industrial Connector Housing is a top-quality solution for industrial and institutional applications. Constructed from durable aluminum with a gray powder coating, this housing ensures long-term reliability in demanding environments. Featuring a double-locking lever and hinged lid, it provides secure cable connections with IP54 protection. With a low-profile design and 16 poles, this connector housing meets stringent RoHS regulations, making it a safe and compliant choice for your electrical connectivity needs.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
IP54
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
BOTTOM BAS GUT GE 16 A
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
None
Model Construction
16
Model Emc Version
No
Model Height
28 mm
Model Hinged Lid
Yes
Model Length
113 mm
Model Locking Mechanism
Double Locking Levers
Model Type
Equipment Mounted (Feed-Through)
Model Type Of Cable
None
Model Width
44 mm
Model With Cable Screw Gland
No
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant with Exceptions
Product Compliance Rohs Exceptions
III-6(a)
Specifications Number Of Poles
16
Specifications Profile
Low
