Wieland BOTTOM BAS GUT GK 24 A Multi-Pole Industrial Connector Housing
Wieland BOTTOM BAS GUT GK 24 A Multi-Pole Industrial Connector Housing
SKU:IND-3b7785
Durable Wieland 24-Pole Industrial Connector Housing, IP54 Rated, UV Resistant, -40°C to 120°C Range
Regular price
$89.99
Regular price
Sale price
$89.99
Unit price
per
Initiate Order
Wieland BOTTOM BAS GUT GK 24 A Multi-Pole Industrial Connector Housing
$89.99
Quantity: 1
Claim Your Seller Account
Wieland BOTTOM BAS GUT GK 24 A Multi-Pole Industrial Connector Housing
$89.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland BOTTOM BAS GUT GK 24 A Multi-Pole Heavy-Duty Industrial Connector Housing is a robust solution constructed from high-grade aluminum with a durable powder coating. Featuring a low-profile design, this housing offers 24 poles and a single locking lever for secure connections. With an IP54 rating, UV resistance, and a wide temperature range from -40°C to 120°C, it ensures reliable performance in harsh industrial environments. Compliant with REACH-SVHC standards, this housing meets stringent quality and safety requirements.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
IP54
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
BOTTOM BAS GUT GK 24 A
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
None
Model Construction
24
Model Emc Version
No
Model Height
28 mm
Model Hinged Lid
No
Model Length
140 mm
Model Locking Mechanism
Single Locking Lever
Model Type
Equipment Mounted (Feed-Through)
Model Type Of Cable
None
Model Width
43 mm
Model With Cable Screw Gland
No
Product Compliance Reach Svhc Conformity Status
Compliant
Specifications Number Of Poles
24
Specifications Profile
Low
