Wieland BOTTOM BAS GUT GK 6 A Heavy-Duty Industrial Connector Housing
Wieland BOTTOM BAS GUT GK 6 A Heavy-Duty Industrial Connector Housing
SKU:IND-867cd4
Durable Wieland 6-pole industrial connector housing with secure locking lever, IP65 protection, and -40°C to 120°C operating range.
Regular price
$69.99
Regular price
Sale price
$69.99
Unit price
per
Initiate Order
Wieland BOTTOM BAS GUT GK 6 A Heavy-Duty Industrial Connector Housing
$69.99
Quantity: 1
Claim Your Seller Account
Wieland BOTTOM BAS GUT GK 6 A Heavy-Duty Industrial Connector Housing
$69.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland BOTTOM BAS GUT GK 6 A Multi-Pole Heavy-Duty Industrial Connector Housing is a robust solution for industrial multipole connections. Constructed from durable aluminum with a gray powder coating, this 6-pole connector features a single locking lever for secure connections. With an IP65 degree of protection, it ensures reliability in challenging environments. This housing is UV resistant, flame-retardant, and operates within a temperature range of -40°C to 120°C.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
IP65
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
BOTTOM BAS GUT GK 6 A
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
None
Model Construction
6
Model Emc Version
No
Model Height
28.9 mm
Model Hinged Lid
No
Model Length
80 mm
Model Locking Mechanism
Single Locking Lever
Model Type
Equipment Mounted (Feed-Through)
Model Type Of Cable
None
Model Width
43.5 mm
Model With Cable Screw Gland
No
Product Compliance Reach Svhc Conformity Status
Compliant
Specifications Number Of Poles
6
Specifications Profile
Low
