Wieland Bottom Bas GUT GS 24 M25 A0 Industrial Connector Housing
Wieland Bottom Bas GUT GS 24 M25 A0 Industrial Connector Housing
SKU:IND-c06729
Durable Wieland Industrial Connector Housing with IP54 Protection & 24-Pole Design. Ideal for industrial applications.
Regular price
$99.99
Regular price
Sale price
$99.99
Unit price
per
Initiate Order
Wieland Bottom Bas GUT GS 24 M25 A0 Industrial Connector Housing
$99.99
Quantity: 1
Claim Your Seller Account
Wieland Bottom Bas GUT GS 24 M25 A0 Industrial Connector Housing
$99.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland Bottom Bas GUT GS 24 M25 A0 Multi-Pole Heavy-Duty Industrial Connector Housing is a top-of-the-line solution for industrial applications. Constructed from durable aluminum with a gray powder coating, this housing features a single locking lever, cable gland M25, and protective cover with an IP54 rating for robust protection. With a low-profile design and 24-pole construction, this connector housing is UV resistant and operates reliably in temperatures ranging from -40°C to 120°C. Ideal for surface mounting, it offers secure cable entry sideways with a gland nut for easy installation. This product is RoHS compliant with exceptions and meets the requirements of various classifications including ECLASS and ETIM standards.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
IP54
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
BOTTOM BAS GUT GS 24 M25 A0
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
Sideways
Model Construction
24
Model Emc Version
No
Model Height
57 mm
Model Hinged Lid
Yes
Model Length
144 mm
Model Locking Mechanism
Single Locking Lever
Model Thread Size M
25
Model Type
Surface Mounting (Base)
Model Type Of Cable
Gland nut
Model Width
57 mm
Model With Cable Screw Gland
Yes
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant with Exceptions
Product Compliance Rohs Exceptions
III-6(a); III-6(c)
Specifications Number Of Poles
24
Specifications Profile
Low
