Wieland Bottom Base GUT GT 16 Multi-Pole Industrial Connector Housing
Wieland Bottom Base GUT GT 16 Multi-Pole Industrial Connector Housing
SKU:IND-962862
Durable Wieland industrial connector housing with 16 poles, IP54 protection, and secure locking lever.
Regular price
$79.99
Regular price
Sale price
$79.99
Unit price
per
Initiate Order
Wieland Bottom Base GUT GT 16 Multi-Pole Industrial Connector Housing
$79.99
Quantity: 1
Claim Your Seller Account
Wieland Bottom Base GUT GT 16 Multi-Pole Industrial Connector Housing
$79.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland Bottom Base GUT GT 16 Multi-Pole Industrial Connector Housing is a heavy-duty solution designed for industrial environments. Constructed from durable aluminum with a powder-coated surface, this 16-pole housing features a single locking lever for secure connections. With a cable gland M25 and IP54 protective cover, it ensures reliable performance in various conditions. UV resistant and capable of operating between -40°C to 120°C, this housing is suitable for demanding applications, offering quality and longevity.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
IP54
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
BOTTOM BAS GUT GT 16 M25 A0
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
Sideways
Model Construction
16
Model Emc Version
No
Model Height
57 mm
Model Hinged Lid
Yes
Model Length
117 mm
Model Locking Mechanism
Single Locking Lever
Model Thread Size M
25
Model Type
Surface Mounting (Base)
Model Type Of Cable
Gland nut
Model Width
57 mm
Model With Cable Screw Gland
Yes
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant with Exceptions
Product Compliance Rohs Exceptions
III-6(a); III-6(c)
Specifications Number Of Poles
16
Specifications Profile
Low
