Wieland Bottom HD GUT GK 25 50 A Industrial Connector Housing
Wieland Bottom HD GUT GK 25 50 A Industrial Connector Housing
SKU:IND-da61d1
Wieland Bottom HD GUT GK 25 50 A Industrial Connector Housing - Aluminum construction, 25 poles, IP54 protection, UV resistant, -40ºC to 120ºC operating temperature.
Regular price
$69.99
Regular price
Sale price
$69.99
Unit price
per
Initiate Order
Wieland Bottom HD GUT GK 25 50 A Industrial Connector Housing
$69.99
Quantity: 1
Claim Your Seller Account
Wieland Bottom HD GUT GK 25 50 A Industrial Connector Housing
$69.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland Bottom HD GUT GK 25 50 A Multi-Pole Heavy-Duty Industrial Connector Housing is expertly crafted from aluminum, featuring a double locking lever for secure connections. With a low profile design and 25 poles, this housing ensures reliable performance in industrial settings. It boasts IP54 protection, UV resistance, and a wide operating temperature range from -40ºC to 120ºC. Compliant with REACH-SVHC standards, this housing is a durable and safe choice for industrial multipole connectors.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
IP54
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
BOTTOM HD GUT GK 25 50 A
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
None
Model Construction
16/25
Model Emc Version
96 mm
Model Hinged Lid
No
Model Length
30.5 mm
Model Locking Mechanism
Single Locking Lever
Model Thread Size Pg
No
Model Type
Equipment Mounted (Feed-Through)
Model Type Of Cable
None
Model Width
45 mm
Model With Cable Screw Gland
No
Product Compliance Reach Svhc Conformity Status
Compliant
Specifications Number Of Poles
25
Specifications Profile
Low
