Wieland BOTTOM MIN GUT GA 7 25 P Multi-Pole Industrial Connector Housing
Wieland BOTTOM MIN GUT GA 7 25 P Multi-Pole Industrial Connector Housing
SKU:IND-952708
Durable Wieland Industrial Connector Housing for heavy-duty industrial applications. IP54 rated, UV resistant, and V0 plastic construction.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Wieland BOTTOM MIN GUT GA 7 25 P Multi-Pole Industrial Connector Housing
$49.99
Quantity: 1
Claim Your Seller Account
Wieland BOTTOM MIN GUT GA 7 25 P Multi-Pole Industrial Connector Housing
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland BOTTOM MIN GUT GA 7 25 P Multi-Pole Heavy-Duty Industrial Connector Housing is a robust solution designed for industrial applications. Constructed with high-quality V0-rated plastic, this housing ensures durability and safety. With an IP54 protection rating, it offers reliable performance in various environments. Featuring a single locking lever mechanism, equipment-mounted design, and UV resistance, it guarantees secure connections and long-term functionality. Operating within a wide temperature range from -40 ºC to 120 ºC, this connector housing is suitable for demanding settings. Its compliance with ECLASS, ETIM, and other industry standards makes it a dependable choice for institutional procurement needs.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
White
General Degree Of Protection Ip
IP54
General Housing Material
Plastic
General Inflammability Class Of Insulation Material According Wi
V0
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
BOTTOM MIN GUT GA 7 25 P
General Surface
Untreated
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
None
Model Construction
3
Model Emc Version
40 mm
Model Hinged Lid
No
Model Length
36.5 mm
Model Locking Mechanism
Single Locking Lever
Model Thread Size Pg
No
Model Type
Equipment Mounted (Feed-Through)
Model Type Of Cable
None
Model Width
23 mm
Model With Cable Screw Gland
No
Specifications Profile
Low
