Wieland EX BUS 16 Screw Industrial Connector Insert
Wieland EX BUS 16 Screw Industrial Connector Insert
SKU:IND-018c5b
Reliable Wieland Industrial Connector Insert for secure and durable connections in industrial settings.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Wieland EX BUS 16 Screw Industrial Connector Insert
$29.99
Quantity: 1
Claim Your Seller Account
Wieland EX BUS 16 Screw Industrial Connector Insert
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland EX BUS 16 2.5 09IA Industrial Connector Insert is a reliable and durable solution for industrial connectivity needs. With a robust design and a female insert type, this connector ensures secure connections in demanding environments. It features copper alloy contacts with tin plating, offering low contact resistance and a long service life. Rated for a nominal voltage of 90V and a maximum operating temperature of 60°C, this connector insert meets strict industrial standards for performance and safety. Compliant with RoHS and REACH-SVHC regulations, it is a sustainable choice for environmentally conscious buyers.
Product Specifications
Classification Eclass 81 Classification
27440205
Classification Etim 40 Classification
EC000438
Classification Etim 50 Classification
EC000438
Classification Etim 60 Classification
EC000438
Classification Etim 70 Classification
EC000438
Connection Data Connection Type
Screw Connection
Connection Data Number Of Poles
16
Contacts Contact Material
Copper Alloy
Contacts Contact Resistance
⤠1.5 mΩ
Contacts Surface
Tin-Plated
Contacts Wire Strip Length
7 mm
General Brands
Wieland
General Color
Blue
General Inflammability Class Of Insulation Material According Wi
Female insert
General Mating Cycles
200
General Maximum Operating Temperature
60 ºC
General Model
FEMALE INSERT EX BUS 16 2,5 09IA
General Pollution Degree
3
General Type
Yes
Note Note
Max. Input current 16A by permitted wire cross section 1.5 till 2.5mm²; Max. Input current 10A by permitted wire cross section 1.0 mm²; Max. Input current 6 A by permitted wire cross section 0.75 mm²; Max. Input current 3 A by permitted wire cross section
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant/Exempted
Product Compliance Rohs Exceptions
III-6(c)
Technical Data Din En 61984 Nominal Voltage
90 V
Technical Data Ulcsa Minimum Flexible Wire Conductor Cross Secti
2.5 mm²
Technical Data Ulcsa Rated Current According Canadian Standards
0.5 A
