Wieland EX BUS 24 2.5 09IA Female Industrial Connector Insert
Wieland EX BUS 24 2.5 09IA Female Industrial Connector Insert
SKU:IND-7473c9
Reliable Wieland 24-pole Female Industrial Connector Insert with screw connection, CSA-rated 0.5A, RoHS & REACH-SVHC compliant.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Wieland EX BUS 24 2.5 09IA Female Industrial Connector Insert
$29.99
Quantity: 1
Claim Your Seller Account
Wieland EX BUS 24 2.5 09IA Female Industrial Connector Insert
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland EX BUS 24 2.5 09IA Female Industrial Connector Insert is a reliable solution for industrial multipole connections. This blue insert features a screw connection with 24 poles, suitable for a rated current of 0.5 A as per CSA standards. The copper alloy contacts with tin-plated surface ensure secure connections with low contact resistance. This explosion-tested insert is compliant with RoHS and REACH-SVHC standards, making it an environmentally friendly choice for industrial applications.
Product Specifications
Classification Eclass 81 Classification
27440205
Classification Etim 40 Classification
EC000438
Classification Etim 50 Classification
EC000438
Classification Etim 60 Classification
EC000438
Classification Etim 70 Classification
EC000438
Connection Data Connection Type
Screw Connection
Connection Data Number Of Poles
24
Contacts Contact Material
Copper Alloy
Contacts Contact Resistance
⤠1.5 mΩ
Contacts Surface
Tin-Plated
Contacts Wire Strip Length
7 mm
General Brands
Wieland
General Color
Blue
General Explosion Tested Version
Yes
General Mating Cycles
200
General Maximum Operating Temperature
60 ºC
General Model
FEMALE INSERT EX BUS 24 2,5 09IA
General Pollution Degree
3
General Type
Female Insert
Note Note
Max. Input current 16A by permitted wire cross section 1.5 till 2.5mm²; Max. Input current 10A by permitted wire cross section 1.0 mm²; Max. Input current 6 A by permitted wire cross section 0.75 mm²; Max. Input current 3 A by permitted wire cross section
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant/Exempted
Product Compliance Rohs Exceptions
III-6(c)
Technical Data Din En 61984 Nominal Voltage
90 V
Technical Data Ulcsa Minimum Flexible Wire Conductor Cross Secti
2.5 mm²
Technical Data Ulcsa Rated Current According Canadian Standards
0.5 A
