Wieland GST15I5S B1 ZR1W WS 5-Pole Indoor Electrical Connector
Wieland GST15I5S B1 ZR1W WS 5-Pole Indoor Electrical Connector
SKU:ELE-b65426
High-quality 5-pole female indoor electrical connector with screw connection, strain relief, and white coding for secure and efficient electrical connections.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Wieland GST15I5S B1 ZR1W WS 5-Pole Indoor Electrical Connector
$29.99
Quantity: 1
Claim Your Seller Account
Wieland GST15I5S B1 ZR1W WS 5-Pole Indoor Electrical Connector
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland GST15I5S B1 ZR1W WS Indoor Connector is a reliable 5-pole female connector with screw connection, designed for cable diameters ranging from 8.5 mm to 12.5 mm. It is rated for mains 250/400 V and 16 A, featuring white color coding for easy identification. With self-locking mechanism and strain relief in white, this connector ensures secure and efficient electrical connections. Made of high-quality polyamide housing and copper zinc contacts, it meets stringent RoHS and REACH-SVHC compliance standards.
Product Specifications
Classification Eclass 81 Classification
27440605
Classification Etim 40 Classification
EC002560
Classification Etim 50 Classification
EC002560
Classification Etim 60 Classification
EC002560
Classification Etim 70 Classification
EC002560
Connection Data Maximum Cable Diameter
12.5 mm
Connection Data Maximum Fine Stranded Connection Cross Section
2.5 mm²
Connection Data Maximum Solid Connection Cross Section
2.5 mm²
Connection Data Minimum Cable Diameter
8.5 mm
Connection Data Minimum Fine Stranded Connection Cross Section
0.5 mm²
Connection Data Minimum Solid Connection Cross Section
0.5 mm²
Connection Data Sheath Strip Length
45 mm
Connection Data Terminations Per Pole
1
Connection Data Wire Strip Length
8 mm
Dimensions Height
15 mm
Dimensions Length
78 mm
Dimensions Width
32 mm
General Brands
Wieland
General Color Of Codingcontact Carrier
White
General Color Of Housing Inclusive Strain Relief
White
General Lockable
Self-Locking (Unlocking by Tool)
General Marking Of Poles
1 | 2 | 3 | N | PE
General Maximum Rated Voltage
600 V
General Mechanical Coding
Code 1
General Model
GST15I5S B1 ZR1W WS
General Number Of Poles
5
General Pollution Degree
2
General Rated Current
16 A
General Rated Impulse Voltage
4 kV
General Strain Relief
Yes
Material Contact Material
Copper Zinc (CuZn)
Material Fire Load
0.109 kW·h
Material Halogen Free
Yes
Material Housing Material
Polyamide
Material Surface Finish
Silver-Plated
Model Connection Type
Female
Model Degree Of Protection Ip
IP20
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
