Wieland HD STS 10 2,5 25 AG Industrial Male Connector Insert
Wieland HD STS 10 2,5 25 AG Industrial Male Connector Insert
SKU:IND-d8199d
Reliable Wieland HD STS 10 2,5 25 AG Industrial Connector Insert for industrial needs. Rated current: 16A, Voltage: 250V, V0 inflammability class, RoHS & REACH-SVHC compliant.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Wieland HD STS 10 2,5 25 AG Industrial Male Connector Insert
$29.99
Quantity: 1
Claim Your Seller Account
Wieland HD STS 10 2,5 25 AG Industrial Male Connector Insert
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland HD STS 10 2,5 25 AG Industrial Male Connector Insert is a top-of-the-line solution for industrial multipole connectors. With a rated current of 16A, maximum voltage of 250V, and a wide operating temperature range from -40°C to 120°C, this insert ensures reliable performance in diverse environments. Featuring a V0 inflammability class, copper alloy contacts with silver-plated surface, and compliance with RoHS and REACH-SVHC standards, this insert guarantees durability and safety in industrial applications.
Product Specifications
Classification Eclass 81 Classification
27440205
Classification Etim 30 Classification
EC000438
Classification Etim 40 Classification
EC000438
Classification Etim 50 Classification
EC000438
Classification Etim 60 Classification
EC000438
Classification Etim 70 Classification
EC000438
Connection Data Connection Type
Screw Connection
Connection Data Maximum Conductor Diameter Rigid Solidstranded
1.5 mm²
Connection Data Minimum Conductor Diameter Rigid Solidstranded
0.5 mm²
Connection Data Number Of Poles
10
Connection Data Protective Contact
Yes
Connection Data Total Number Of Poles Without Ground Contact
10
Connection Data With Wire Protection
Yes
Contacts Contact Material
Copper Alloy
Contacts Contact Resistance
⤠4 mΩ
Contacts Surface
Silver-Plated
Contacts Wire Strip Length
7 mm
General Brands
Wieland
General Color
Gray
General Inflammability Class Of Insulation Material According Wi
V0
General Mating Cycles
100
General Maximum Operating Temperature
120 ºC
General Minimum Operating Temperature
-40 ºC
General Model
MALE INSERT HD STS 10 2,5 25 AG
General Modular Version
No
General Pollution Degree
3
General Type
Male Insert
Model With Housing
No
Product Compliance Reach Svhc Conformity Status
Compliant
Product Compliance Rohs Conformity Status
Compliant
Screws Head Design Clamping Screws
H1/0.5-0.7 N·m
Screws Head Design Ground Conductor Screws
Z2/1.2 N·m
Screws Head Design Mounting Screws
Z1/0.5 N·m
Technical Data Din En 61984 Maximum Rated Voltage Faceground
250 V
Technical Data Din En 61984 Nominal Current
16 A
Technical Data Din En 61984 Nominal Voltage
250 V
Technical Data Din En 61984 Rated Impulse Voltage
4 kV
Technical Data Ulcsa Flexible Wire Conductor Cross Section
20-14 AWG
Technical Data Ulcsa Maximum Flexible Wire Conductor Cross Secti
2.5 mm²
Technical Data Ulcsa Maximum Rated Voltage According To Underwri
600 V
