Wieland Heavy-Duty Industrial Connector Housing
Wieland Heavy-Duty Industrial Connector Housing
SKU:IND-b7bb12
Durable Wieland Industrial Connector Housing with IP54 rating, ideal for demanding industrial settings. Single locking lever mechanism for secure connections.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.

The Wieland Heavy-Duty Industrial Connector Housing is a top-quality solution for industrial multipole connections. Constructed with durable cast zinc material and a powder coating for added protection, this housing ensures reliability in various operating conditions. With an IP54 rating, it offers resistance to dust and water, making it suitable for demanding industrial environments. The single locking lever mechanism provides secure connections, while the UV resistance enhances outdoor durability. This model is compliant with ECLASS 8.1 and ETIM 7.0 classifications, meeting industry standards for quality and performance.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
IP54
General Housing Material
Cast Zinc
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
BOTTOM MIN GUT GB 7 25 Z
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
None
Model Construction
3
Model Emc Version
40 mm
Model Hinged Lid
No
Model Length
26 mm
Model Locking Mechanism
Single Locking Lever
Model Thread Size Pg
No
Model Type
Equipment Mounted (Feed-Through)
Model Type Of Cable
None
Model Width
40.5 mm
Model With Cable Screw Gland
No
Specifications Profile
Low
