Wieland Heavy-Duty Industrial Connector Housing - 40-Pole M25 Threaded
Wieland Heavy-Duty Industrial Connector Housing - 40-Pole M25 Threaded
SKU:IND-484e36
Wieland Industrial Connector Housing - Heavy-Duty, 40-Pole M25 Threaded, Aluminum Construction, UV Resistant, RoHS Compliant
Regular price
$99.99
Regular price
Sale price
$99.99
Unit price
per
Initiate Order
Wieland Heavy-Duty Industrial Connector Housing - 40-Pole M25 Threaded
$99.99
Quantity: 1
Claim Your Seller Account
Wieland Heavy-Duty Industrial Connector Housing - 40-Pole M25 Threaded
$99.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland HOOD BAS GOT GG 40HM25 50 A1 Multi-Pole Heavy-Duty Industrial Connector Housing is engineered for reliability in industrial environments. Constructed from robust aluminum with a gray powder coating, this housing features a single locking lever and a threaded hole M25 on the right side, suitable for 40-pole connections. With UV resistance and a wide temperature range from -40°C to 120°C, it ensures durability and performance. Compliant with RoHS standards, this low-profile connector housing is ideal for demanding applications where quality and longevity are essential.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
Other
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
HOOD BAS GOT GG 40HM25 50 A1
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
Sideways
Model Construction
16H
Model Emc Version
No
Model Height
76 mm
Model Hinged Lid
No
Model Length
94 mm
Model Locking Mechanism
Single Locking Lever
Model Thread Size M
25
Model Type
Male
Model Type Of Cable
Thread
Model Width
43 mm
Model With Cable Screw Gland
No
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant with Exceptions
Product Compliance Rohs Exceptions
III-6(a)
Specifications Number Of Poles
40
Specifications Profile
Low
