Wieland Heavy-Duty Industrial Connector Housing - 40 Poles, Threaded M32, Aluminum
Wieland Heavy-Duty Industrial Connector Housing - 40 Poles, Threaded M32, Aluminum
SKU:IND-ea4cb9
Enhance industrial connectivity with Wieland 40-Pole Heavy-Duty Connector Housing
Regular price
$79.99
Regular price
Sale price
$79.99
Unit price
per
Initiate Order
Wieland Heavy-Duty Industrial Connector Housing - 40 Poles, Threaded M32, Aluminum
$79.99
Quantity: 1
Claim Your Seller Account
Wieland Heavy-Duty Industrial Connector Housing - 40 Poles, Threaded M32, Aluminum
$79.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your industrial connectivity with the Wieland HOOD BAS GOT GA 40HM32 50 A1 Multi-Pole Heavy-Duty Industrial Connector Housing. Crafted from durable aluminum with a gray powder coating, this housing ensures robust protection for your connections. Featuring a low profile design, it is built for reliability in demanding environments. With a UV-resistant construction and a wide operating temperature range from -40°C to 120°C, this housing is suitable for various industrial applications. Equipped with a double locking lever mechanism, cable entry with a threaded M32 hole, and compliance with REACH-SVHC standards, this connector housing offers both performance and peace of mind.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
Other
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
HOOD BAS GOT GA 40HM32 50 A1
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
Sideways
Model Construction
16H
Model Emc Version
No
Model Height
76 mm
Model Hinged Lid
No
Model Length
94 mm
Model Locking Mechanism
Double Locking Levers
Model Thread Size M
32
Model Type
Male
Model Type Of Cable
Thread
Model Width
56 mm
Model With Cable Screw Gland
No
Product Compliance Reach Svhc Conformity Status
Compliant
Specifications Number Of Poles
40
Specifications Profile
Low
