Wieland Heavy-Duty Industrial Connector Housing M20 Threaded, Gray
Wieland Heavy-Duty Industrial Connector Housing M20 Threaded, Gray
SKU:IND-65b74d
Durable Wieland Connector Housing for industrial applications, cast zinc with M20 threaded hole, gray color, UV resistant, temperature range -40°C to 120°C.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Wieland Heavy-Duty Industrial Connector Housing M20 Threaded, Gray
$49.99
Quantity: 1
Claim Your Seller Account
Wieland Heavy-Duty Industrial Connector Housing M20 Threaded, Gray
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland Heavy-Duty Industrial Connector Housing is a robust solution ideal for industrial applications. Constructed from cast zinc with a gray powder coating, this multi-pole connector meets stringent quality standards. With a temperature range from -40°C to 120°C, UV resistance, and a single locking lever mechanism, it ensures reliable performance in diverse environments. Designed with a low profile and EMI protection, this housing offers secure cable connections and durability.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
Other
General Housing Material
Cast Zinc
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
HOOD MIN GOT GA 7 M20 25 Z1
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
Sideways
Model Construction
3
Model Emc Version
No
Model Height
48 mm
Model Hinged Lid
No
Model Length
36 mm
Model Locking Mechanism
Single Locking Lever
Model Thread Size M
20
Model Type
Male
Model Type Of Cable
Thread
Model Width
36 mm
Model With Cable Screw Gland
No
Specifications Profile
Low
