Wieland Heavy-Duty Multi-Pole Industrial Connector Housing
Wieland Heavy-Duty Multi-Pole Industrial Connector Housing
SKU:IND-cace5e
Durable Wieland connector housing with cast zinc construction, UV resistant, and wide temperature range - ideal for industrial applications.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Wieland Heavy-Duty Multi-Pole Industrial Connector Housing
$49.99
Quantity: 1
Claim Your Seller Account
Wieland Heavy-Duty Multi-Pole Industrial Connector Housing
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland Heavy-Duty Multi-Pole Industrial Connector Housing is a top-tier solution for industrial applications. Constructed with cast zinc and a powder coating, it ensures durability and resistance. This connector housing features a single locking lever, M20 threaded hole, and a low profile design suitable for demanding environments. With a wide temperature range from -40°C to 120°C, UV resistance, and EHV for secure cable connections, this housing meets stringent industrial standards, guaranteeing reliability and performance.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
Other
General Housing Material
Cast Zinc
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
HOOD MIN GOT GC 7 M20 25 Z1
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
Above
Model Construction
3
Model Emc Version
No
Model Height
53.5 mm
Model Hinged Lid
No
Model Length
26.8 mm
Model Locking Mechanism
Single Locking Lever
Model Thread Size M
20
Model Type
Cable Coupler
Model Type Of Cable
Thread
Model Width
36.5 mm
Model With Cable Screw Gland
No
Specifications Profile
Low
