Wieland HOOD BAS GOT GA 10 M20 A0 Multi-Pole Heavy-Duty Connector Housing
Wieland HOOD BAS GOT GA 10 M20 A0 Multi-Pole Heavy-Duty Connector Housing
SKU:IND-21a125
Durable aluminum multi-pole connector housing with secure locking levers, IP54 protection, and RoHS compliance. Ideal for industrial use.
Regular price
$79.99
Regular price
Sale price
$79.99
Unit price
per
Initiate Order
Wieland HOOD BAS GOT GA 10 M20 A0 Multi-Pole Heavy-Duty Connector Housing
$79.99
Quantity: 1
Claim Your Seller Account
Wieland HOOD BAS GOT GA 10 M20 A0 Multi-Pole Heavy-Duty Connector Housing
$79.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland HOOD BAS GOT GA 10 M20 A0 Multi-Pole Heavy-Duty Industrial Connector Housing is a top-notch solution crafted from aluminum with a gray powder coating. Featuring a 10-pole construction, this housing offers exceptional durability and IP54 protection. With a temperature range from -40°C to 120°C, UV resistance, and compliance with RoHS standards, it ensures reliability in industrial settings. The double locking levers and cable gland M20 on the side provide secure connections, making it ideal for various applications. Whether for double-locking lever or screw cap usage, this housing meets stringent industrial requirements.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
IP54
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
HOOD BAS GOT GA 10 M20 A0
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
Sideways
Model Construction
10
Model Emc Version
No
Model Height
53 mm
Model Hinged Lid
No
Model Length
73 mm
Model Locking Mechanism
Double Locking Levers
Model Thread Size M
20
Model Type
Male
Model Type Of Cable
Gland nut
Model Width
43 mm
Model With Cable Screw Gland
Yes
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant with Exceptions
Product Compliance Rohs Exceptions
III-6(c)
Specifications Number Of Poles
10
Specifications Profile
Low
