Wieland HOOD BAS GOT GI 10 M20 A1 Heavy-Duty Industrial Connector Housing
Wieland HOOD BAS GOT GI 10 M20 A1 Heavy-Duty Industrial Connector Housing
SKU:IND-cd34f1
Durable Wieland connector housing with single locking lever, aluminum construction, and 10 poles. UV resistant and RoHS compliant.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Wieland HOOD BAS GOT GI 10 M20 A1 Heavy-Duty Industrial Connector Housing
$49.99
Quantity: 1
Claim Your Seller Account
Wieland HOOD BAS GOT GI 10 M20 A1 Heavy-Duty Industrial Connector Housing
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland HOOD BAS GOT GI 10 M20 A1 Heavy-Duty Industrial Connector Housing is a robust solution designed for industrial applications. Constructed from aluminum with a gray powder coating, this housing features a single locking lever with a threaded hole M20 on the top for secure connections. With a low profile design and 10 poles, it offers durability with a wide operating temperature range (-40°C to 120°C). This connector housing meets RoHS compliance and is UV resistant, making it ideal for demanding environments.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
Other
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
HOOD BAS GOT GI 10 M20 A1
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
Above
Model Construction
10
Model Emc Version
No
Model Height
53 mm
Model Hinged Lid
No
Model Length
89 mm
Model Locking Mechanism
Single Locking Lever
Model Thread Size M
20
Model Type
Male
Model Type Of Cable
Thread
Model Width
43 mm
Model With Cable Screw Gland
No
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant with Exceptions
Product Compliance Rohs Exceptions
III-6(a)
Specifications Number Of Poles
24
Specifications Profile
Low
