Wieland HOOD MIN GOT GC 7 M20 25 Z0 Multi-Pole Industrial Connector Housing
Wieland HOOD MIN GOT GC 7 M20 25 Z0 Multi-Pole Industrial Connector Housing
SKU:IND-a7281f
Durable Wieland industrial connector housing with IP54 protection, UV resistance, and wide temperature range for reliable performance.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
Wieland HOOD MIN GOT GC 7 M20 25 Z0 Multi-Pole Industrial Connector Housing
$39.99
Quantity: 1
Claim Your Seller Account
Wieland HOOD MIN GOT GC 7 M20 25 Z0 Multi-Pole Industrial Connector Housing
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland HOOD MIN GOT GC 7 M20 25 Z0 Multi-Pole Industrial Connector Housing is a heavy-duty solution for industrial multipole connections. Constructed with durable cast zinc housing and a powder coating for longevity, this connector features an IP54 degree of protection, making it ideal for harsh environments. With a UV-resistant, low-profile design and a wide operating temperature range from -40°C to 120°C, it ensures reliable performance in diverse settings. The single locking lever mechanism and cable coupler type provide secure cable connections, while its compliance with ECLASS 8.1 and ETIM classifications guarantees quality and compatibility.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
IP54
General Housing Material
Cast Zinc
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
HOOD MIN GOT GC 7 M20 25 Z0
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
Above
Model Construction
3
Model Emc Version
No
Model Height
60 mm
Model Hinged Lid
No
Model Length
26.8 mm
Model Locking Mechanism
Single Locking Lever
Model Thread Size M
20
Model Type
Cable Coupler
Model Type Of Cable
Gland nut
Model Width
36.5 mm
Model With Cable Screw Gland
Yes
Specifications Profile
Low
