The Wieland HOOD BAS GOT GG 6 M20 A0 Multi-Pole Heavy-Duty Industrial Connector Housing is a high-quality aluminum construction designed for industrial applications. Featuring a single locking lever and a cable gland M20 on the right side, this connector housing offers secure connections and IP54 protection. With a low profile design and powder coating for added durability, this robust connector housing can withstand temperatures from -40°C to 120°C. Its 6-pole configuration ensures reliable and efficient connectivity, making it ideal for demanding industrial environments.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
IP54
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
HOOD BAS GOT GG 6 M20 A0
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
Sideways
Model Construction
6
Model Emc Version
No
Model Height
51 mm
Model Hinged Lid
No
Model Length
73.6 mm
Model Locking Mechanism
Single Locking Lever
Model Thread Size M
20
Model Type
Male
Model Type Of Cable
Gland nut
Model Width
43 mm
Model With Cable Screw Gland
Yes
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant with Exceptions
Product Compliance Rohs Exceptions
III-6(c)
Specifications Number Of Poles
6
Specifications Profile
Low
