Wieland Industrial 6-Pole Connector Housing with M20 Thread & Protective Cover
Wieland Industrial 6-Pole Connector Housing with M20 Thread & Protective Cover
SKU:IND-9fb06b
Premium 6-pole industrial connector housing with M20 thread, single locking lever, and protective cover.
Regular price
$69.99
Regular price
Sale price
$69.99
Unit price
per
Initiate Order
Wieland Industrial 6-Pole Connector Housing with M20 Thread & Protective Cover
$69.99
Quantity: 1
Claim Your Seller Account
Wieland Industrial 6-Pole Connector Housing with M20 Thread & Protective Cover
$69.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland BOTTOM BAS GUT GS 6 M20 A1 Multi-Pole Heavy-Duty Industrial Connector Housing is a premium solution for industrial connectivity. Constructed from durable aluminum with a gray powder coating, this housing is built to withstand harsh environments. Featuring a single locking lever, threaded M20 hole, and a protective cover, it ensures secure cable connections with a low profile design. With a temperature range of -40°C to 120°C, UV resistance, and RoHS compliance, this connector housing offers reliability and safety for various industrial applications.
Product Specifications
Classification Eclass 81 Classification
27440202
Classification Etim 30 Classification
EC000437
Classification Etim 40 Classification
EC000437
Classification Etim 50 Classification
EC000437
Classification Etim 60 Classification
EC000437
Classification Etim 70 Classification
EC000437
General Brands
Wieland
General Color
Gray
General Degree Of Protection Ip
Other
General Housing Material
Aluminum
General Inflammability Class Of Insulation Material According Wi
Other
General Maximum Operating Temperature Range
120 ºC
General Minimum Operating Temperature Range
-40 ºC
General Model
BOTTOM BAS GUT GS 6 M20 A1
General Surface
With Powder Coating
General Ultraviolet Uv Resistant
Yes
Model Cable Entry
Sideways
Model Construction
6
Model Emc Version
No
Model Height
54.5 mm
Model Hinged Lid
Yes
Model Length
84 mm
Model Locking Mechanism
Single Locking Lever
Model Thread Size M
20
Model Type
Surface Mounting (Base)
Model Type Of Cable
Thread
Model Width
52 mm
Model With Cable Screw Gland
No
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant with Exceptions
Product Compliance Rohs Exceptions
III-6(a)
Specifications Number Of Poles
6
Specifications Profile
Low
